Elegoo OrangeStorm Giga - Large Format Filament 3D Printer

Elegoo OrangeStorm Giga: Large Format Filament 3D Printer


The OrangeStorm Giga is Elegoo’s latest large-format 3D printer. It promises a massive build volume, fast print speeds, multiple extruders, and more at a pre-order price of $2,499. Breaking away from the typical Solar System-themed names of the Elegoo product lines (Jupiter, Neptune, Mars, etc.), the OrangeStorm Giga stands apart both in naming convention and overall size.




Table of Contents

Price: $2,500
Product Affiliate Links: 3DWithUs is supported by its audience. Purchases via some links may earn us a small commission at no extra cost to you. This helps us to continue bringing you high-quality content. Our guides and reviews remain unbiased and independent.

Elegoo OrangeStorm Giga 3D Printer

Official Website

The OrangeStorm Giga was launched on Kickstarter on November 4th, and the campaign quickly became successful.

2,005 backers pledged $3,386,996 to help bring this project to life.

Interested in learning more about the OrangeStorm Giga? Keep reading to discover more about the technical specs and surprises that this large format filament 3D printer has in store. From multiple extruders to a build platform composed of four independently controlled heating elements, the OrangeStorm Giga will likely quickly find a home in prosumer shops looking to increase the maximum size parts they offer.

Elegoo OrangeStorm Giga
Elegoo OrangeStorm Giga FDM 3D Printer
Image: Elegoo

Test at Tradeshow

We had a chance to witness Elegoo OrangeStorm Giga in action at the 3D printing tradeshow Formnext. The Elegoo team were confident enough to keep the print going for the whole day and here is the result.

Elegoo OrangeStorm Giga at Trade Show - First Layer
Elegoo OrangeStorm Giga at Trade Show – First Layer
©3DWithUs
OrangeStorm 3 Hour Print in Process - 0.6mm Nozzle
OrangeStorm Giga Printing with 0.6mm Nozzle – 3 Hours Print
OrangeStorm Giga - 8 Hours in Printing
8 Hours in Printing

– Nozzle Sizes. The upgraded nozzle of the printer features a 300℃ high-temperature capability with a double-gear extrusion structure made from full titanium alloy and a chrome zirconium copper nozzle, complemented by a 60W ceramic heating pad for more consistent and precise extrusion. Such a nozzle is incompatible with those on the previous Neptune 4 series, including Plus and Max.

Nozzle Diameter(included): 0.6mm
Nozzle Diameter(optional): 0.4mm/ 0.8mm/ 1mm

Large Build Volume

The Elegoo OrangeStorm Giga features a build volume of 800mm x 800mm x 1000mm (31.5” x 31.5” x 39.4”), significantly larger than other FDM 3D printers offered by Elegoo. The OrangeStorm Giga is equipped with drag chain cable carriers on the X and Z axes, which prevent cables from fraying while printing and extending across a large range of motion.

Extruders
Orange Extruders on OrangeStorm Giga
Image: Elegoo

Multiple Extruder Configuration

The OrangeStorm Giga can be equipped with up to four independent extruder assemblies for printing multiple colors or materials. The extruder modules are equipped with a 300℃ high-temperature nozzle, a 60W ceramic heating pad, and a dual-gear extruder combined with a built-in acceleration sensor for consistent printing at high speeds. The OrangeStorm Giga is advertised as having a top speed of 300mm/s, with a more conservative recommended speed of 150mm/s.

Other Features

The OrangeStorm Giga has all of the features that you would expect in a higher-end consumer FDM 3D printer, including filament detection, a large 7-inch LCD touchscreen, power loss recovery, and silent stepper drivers. The OrangeStorm Giga uses a silent TMC2209 stepper driver on the X and E-axes, a TMC5160 on the Y-axis, and a pair of 35774 drivers for the Z-axis.


An interesting feature of the OrangeStorm Giga is the heated build platform, which is composed of four independently heated removable magnetic PEI platforms. These four platforms are advertised as being able to be heated simultaneously to 90°C in 17 minutes. The four platforms can be manually or automatically controlled, with the printer being capable of heating only the platforms on which the model is being built to reduce energy consumption and increase efficiency.

Campaign

The OrangeStorm Giga was launched on Kickstarter on November 4th, and the campaign quickly became successful.

2,005 backers pledged $3,386,996 to help bring this project to life.

A year later, while most of the pledges were fulfilled, it is a good idea to check the Kickstarter Campaigns comment section to do pre-purchasing research. There is a lot of information that can give a clue about how to operate such a big 3D printer successfully.

Disclaimer: As with all crowdfunding campaigns, it’s important to note that a pledge is not a purchase or a pre-order, and there is no guarantee that the machine will be produced or shipped. Elegoo is an established company that has successfully completed and fulfilled crowdfunding campaigns in the past, but it’s important to be aware of the risks when making a pledge.

Compare OrangeStrom Giga to Other 3D Printers:

Compare to the Elegoo Neptune series 3D printers:

Together, the Elegoo Neptune 4, Neptune 4 Pro, Neptune 4 Plus, and Neptune 4 Max constitute the latest products in the Neptune FDM 3D printer series. If some of the machines haven’t been reviewed on our website yet, you can refer to their primary comparison table in the image below to get a general overview.

Elegoo Neptune 4 Pro, Neptune 4 Plus and Neptune Max Comparison
Elegoo Neptune 4 Pro, Neptune 4 Plus and Neptune Max Comparison
Image: Elegoo

On 3DWithUs, we have a comprehensive comparison guide covering FDM 3D printers. Currently, there is a limited competition to OrangeStorm Giga in this technology, build volume size and price segment. We are happy that Elegoo continues to push FDM printer technology to new heights, bringing affordable machines to a broader market.


Read more: Elegoo Neptune 4 Max Review: 3D Printer Testing, Settings, Tips

As the consumer desktop FDM 3D printer market goes through the ‘print speed race’, Elegoo updated its Plus and Max size Neptune 3D printers to new versions. Klipper firmware-enabled technology, a higher-temperature dual gear extruder, and an extra cooling feature pushed the Neptune 4 Max to come with the default high printing speed. Read more and images…

Elegoo Neptune 4 Max and Prints Compilation
Elegoo Neptune 4 Max and Test Prints
Featured Designs: 3DWithUs
©3DWithUs – Prints and Photo: Max Funkner

Conclusion

A year after the initial campaign, Elegoo fulfilled most of the pledges, and the machine is now available to pre-order on the official website.
