Anycubic Photon M3 Plus Review – Settings and Testing 6K Resin Printer


The Anycubic Photon M3 Plus is the middle child of the new M3 line from Anycubic, but don’t let that designation fool you into thinking it lacks distinguishing features. The Photon M3 Plus is a large format resin 3D printer with a 6K Mono LCD that offers large parts, high resolution, and a blazing fast per-layer cure time of 1.5 seconds. In addition, the M3 Plus features a unique automatic resin vat filling system, an optional camera for monitoring prints, and Wi-Fi connectivity through the newly released Anycubic Cloud ecosystem. Coming in at $699, the M3 Plus packs a lot of functionality into its ~26 lb. frame, and will no doubt be a common sight in the prosumer market.

Anycubic Photon M3 Plus Specifications

Layer Height: .010mm to .15mm
X/Y Resolution: 34 micron
Print Speed: 1.5 sec / layer
Build Volume: 197 x 122 x 245 mm / 7.8” x 4.8” x 9.6”
Material: 405nm wavelength UV resin
Masking LCD Resolution: 5760 x 3600 px
Masking LCD Size: 9.25” Mono LCD
Connectivity: USB Thumb Drive, LAN, Wi-Fi
Interface: 5” Color Touchscreen LCD
Affiliate links:
Anycubic Photon M3 Plus
Amazon
AliExpress
Official Website

Hardware Features and Review

Weighing in at just over 26 pounds, the Anycubic Photon M3 Plus is a sturdy machine that feels significantly more robust than lower-cost resin printers, which tend to have plastic frames. The primary interface of the M3 Plus is the 5-inch color LCD touchscreen on the front of the printer which is bright, responsive, and gives the printer a professional appearance.

5-inch LCD interface on M3 Plus
5-inch LCD interface
© 3DWithUs – Photo: Andrew Sink

The Photon M3 Plus uses a 9.25-inch 6K masking LCD with an X/Y resolution of 34 microns, which gives it a higher resolution than the similarly sized Anycubic Photon Mono X, which features an X/Y resolution of 50 microns.

M3 Plus Dual Z linear rails
Dual Z linear rails
© 3DWithUs – Photo: Andrew Sink

Photon M3 Plus 3D Printing Volume

The large volume (7.8 x 4.8 x 9.6 inches) of the M3 Plus is impressive for a resin 3D printer, and it has been designed to allow the user to maximize the usage of this volume. The Photon M3 Plus uses a pair of linear rails on the ball screw-driven Z-axis for smooth and precise movement of the gantry. The gantry is a solid block of machined metal which feels sturdy and robust with no play or wiggle during printing.

Printing platform leveling
Leveling the build platform requires tightening four bolts
© 3DWithUs – Photo: Andrew Sink

Build Platform Leveling

Just like the Anycubic Photon Mono X, the Photon M3 Plus uses a four bolt leveling system to align the build platform with the masking LCD. This system is easy to use, and Anycubic includes a special sheet of paper that can act as a feeler gauge during leveling. I simply placed the sheet of paper on top of the masking LCD, homed the Z axis, and tightened the four bolts on the Z gantry. Once this process is complete, the bed is leveled and the printer is ready to print. I leveled the printer once after receiving it, and did not need to make any adjustments throughout the rest of this review.

Texture on a build platform
The laser-etched pattern on the build platform

The build platform on the Anycubic Photon M3 Plus features an innovative laser-etched pattern which helps to increase the bond between the first layer and the platform. Models with a large footprint or wide cross-section on the first layer tend to delaminate at the edges, which can lead to the part peeling from the platform during printing. This etched pattern worked well during testing, and I didn’t have any issues with models not adhering to the platform.

Automatic resin vat filler
Automatic resin vat filler
© 3DWithUs – Photo: Andrew Sink

Anycubic Automatic Resin Pump System

The Photon M3 Plus features an automatic resin vat pump, a new feature which is designed to automatically detect when the resin vat is running low and automatically add material without pausing the print. “How do I add resin during printing?” is a common question among new users, and this automatic pump seeks to solve this problem before it even occurs. The pump uses two metal pins to detect resin in the vat and when the circuit is opened, air is pumped into the resin bottle (mounted behind the printer), which causes resin to pour from the tube.

Resin bottle attachment for automatic pumping
Resin bottle attachment for automatic vat filling
© 3DWithUs – Photo: Andrew Sink

While the automatic pump works well, the amount of tubes, wires, and probes make this system look a little less professional, and a little more like a science project. In addition, the black tube which delivers the resin will need to be flushed whenever resin is changed to fully change colors and to prevent it from potentially hardening and blocking the stream.


While I liked the system overall, it does raise a few questions regarding maintenance and long-term storage. If you primarily print with a single type/color of resin and simply want to make large parts without worrying about the vat running out, this is a feature you will enjoy using.

Automatic Resin Vat Filler
The automatic pump system
© 3DWithUs – Photo: Andrew Sink
The automatic pump system
The automatic pump uses multiple wires, hoses, and probes
© 3DWithUs – Photo: Andrew Sink

Anycubic LighTurbo Light Source

Anycubic’s LighTurbo Light Source is the name given to the combination of masking LCD, optical lens, lens bracket, and LED light source that is used in the new Photon M3 series of printers: the Photon M3, the Photon M3 Plus, and the Photon M3 Max. This light source is designed with speed and consistency in mind, and allows the Photon M3 Plus printer to ship with a native 1.4 second per-layer cure time.

The LighTurbo Matrix Light Source
The LighTurbo Matrix Light Source inside the Anycubic Photon M3
©3DWithUs – Photo: Andrew Sink

The LighTurbo Matrix Light Source is a UV LED array that is designed specifically to project light evenly across the build surface. Here’s an explanation from Anycubic: “The LED beads project light to the optical lens during printing, which will refract all the diffuse rays and turn them into parallel light.”


Photon M3 Plus Testing – Anycubic Test and Other Prints

The Anycubic Photon M3 Plus only included a single demo model: a latticed cube with the Anycubic logo suspended inside of it. The pre-sliced model is loaded in a print-ready format on the included USB drive, and it printed without any issues.

Anycubic Test Print - Photon M3 Plus
Demo model after printing
© 3DWithUs – Photo: Andrew Sink

An interesting note: the lattice is capable of printing without support material, but this model included supports on the underside of one of the Anycubic logos, and not the other. Anycubic may be attempting to demonstrate the ability of the machine to print without support material on certain geometries, but that could have been made clearer with additional text or graphics on the part.

The printed Anycubic demo model
The printed demo model
© 3DWithUs – Photo: Andrew Sink
The Power Loader - Model Preview in Photon Workshop
A model prepared in Photon Workshop

Settings – Printing with Photon Workshop

The Anycubic Photon M3 Plus uses Photon Workshop to prepare 3D models for printing, and a version of this software comes loaded on the USB stick included with the printer. I used a pre-supported model from Loot Studios to test out the slicer and focus on the resin settings. Using the default 50 micron settings, I sliced the model and saved the print-ready file to a USB drive for printing.

Anycubic Basic Resin Settings for M3 Plus
Anycubic Basic Resin Settings for Photon M3 Plus
Screenshot: Photon Workshop
Power Loader 3D Model with Supports
Power Loader with supports – miniature by Loot Studios
© 3DWithUs – Print & Photo: Andrew Sink
Power Loader 3D Printed Model
Model after support removal, washing, and curing
© 3DWithUs – Print & Photo: Andrew Sink
Power Loader - 3D Printed Model Details
Power Loader – 3D Printed Model Details
© 3DWithUs – Print & Photo: Andrew Sink

Using Anycubic Basic resin, the Power Loader model printed without any issues and was easily removed from the build platform. The support material was easy to remove, and the detail on the model was superb. Small details like bolts and fasteners were easy to identify, and the overall quality of the print was readily apparent. The benefit of the 34 micron X/Y resolution from the 6K masking LCD is clear; small details are sharp and in-focus without compromising on print speed.

3D Scanned and Printed Statuette of Salus
3D Scanned and Printed Statuette of Salus
© 3DWithUs – Scan, Print & Photo: Andrew Sink

Photon Workshop can also generate supports automatically, which I used to print a 3D scan of the Statuette of Salus, a marble sculpture that is over 1900 years old. This 3D scan was made using Polycam, a 3D scanning app which only requires a smartphone. You can learn more about Polycam in our guided tutorial if you’re interested in making 3D scans of your own. The support material detached easily from the print, and the organic curves of the marble were captured perfectly by the Photon M3 Plus.

Anycubic Cloud Interface Screenshots
Anycubic Cloud interface on iOS

Anycubic Cloud – Testing the App

The Anycubic Photon M3 Plus is designed to work with the newly released Anycubic Cloud; a cloud-based file transfer system that allows users to start the M3 Plus remotely. Anycubic Cloud requires an iOS or Android app as part of the workflow, so you’ll need to use a mobile phone for printing. The general workflow starts in Photon Workshop with a model that is prepared for printing and sliced. From there, it is uploaded to the Anycubic Cloud account of the user, where it can then be accessed through the Anycubic Cloud phone app. This workflow requires the printer, cell phone, and computer running Anycubic Cloud all be connected to the internet.


The app itself is useful (I used it to start a few prints and was impressed with the upload/download speed) and it worked perfectly during testing. However, I did find myself wishing for a way to start prints directly from Photon Workshop without using a phone, which felt a bit like an extra step. There is also an optional camera that allows for wireless monitoring of prints, but the firmware version at the time of this review did not support this accessory. This section will be updated when the firmware is updated. The statistics on Anycubic Cloud are a nice touch, and the ability to see resin consumption and number of successful prints is a great way to track the productivity of a machine.

A filled M3 Plus build platform preview
A filled M3 Plus build platform preview

Optional Camera

The optional camera on the Anycubic Photon M3 Plus attaches on the rear of the base, and features two points of articulation to help you capture the perfect shot. The camera works by streaming live video to Anycubic Cloud, so you can monitor the status of your print from the app.

Optional Camera for Photon M3 Plus 3D Printer
Optional Camera Attachment on the Photon M3 Plus
Photo: Andrew Sink

In addition to showing statistics related to the print, the live video feed allows users to see their print in real time. The camera doesn’t output a particularly high resolution image, but it is perfectly suitable for monitoring the status of a print in real time. At the time of this article, Anycubic cloud doesn’t offer any additional features such as capturing or storing images, but I found it was easy to screenshot the app to capture frames during printing.

3D printing live video feed
Live video feed
Screenshot: Anycubic Cloud Interface

Large Volume Printing on the Anycubic Photon M3 Plus

One of the biggest draws of a large format resin 3D printer is the ability to produce multiple parts simultaneously while reducing the overall cycle time per part. The large build platform of the M3 Plus is perfect for printing large objects; split up or in a single piece. To test this out, I printed the Laser Cannon from Loot Studios on a single platform by laying out all five pieces at once. This is a large terrain piece that would typically require multiple prints, but the large build volume of the Photon M3 Plus allows the entire model to be printed at once.

Resin 3D Printed Laser Model
Laser Model by Loot Studios
© 3DWithUs – Print & Photo: Andrew Sink
Mech Model in Anycubic Basic Grey Resin
Mech Model in Anycubic Basic Grey Resin
© 3DWithUs – Print & Photo: Andrew Sink

This model has alignment pins to aid assembly, and the overall accuracy of the model made this process simple. I was impressed with the level of detail captured, and the Photon M3 Plus printed out the initial wide cross-section with no difficulty. Despite the weight of this model (printed completely solid), it adhered to the build platform and didn’t peel or delaminate during printing.

M3 Plus
High detail and large volume are no problem for the Anycubic M3 Plus
© 3DWithUs – Photo: Andrew Sink

Tough Resin Test and Settings

Here is the print with the RESIONE M68 Tough White resin. I downloaded the profile bundle for Photon Workshop and uploaded the M68 profile. Please find the screenshot below.

Red-Eyed Skink 3D Print
Red-Eyed Skink by Trejager – 3D Print in M68 Tough White
Print and Photo: Andrew Sink
Photon Workshop Screenshot - Resin Settings
RESIONE M68 Tough Resin Settings for Photon M3 Plus
Screenshot: Photon Workshop

Conclusion

For this review, I tested the printer for a few weeks. The large volume, sturdy construction, and high resolution of the Anycubic M3 Plus make it a very strong contender for anyone interested in a reliable resin 3D printer. In addition, the Anycubic Cloud software, automatic resin vat filing, optional camera, and other features make the M3 stand out amongst the competition. The fast per-layer cure time of 1.5 seconds, 34 micron XY resolution, and sturdy Z-axis gantry have made this printer a personal favorite, and I have no doubt that it will soon have a growing user base.

Affiliate links:
Anycubic Photon M3 Plus
Amazon
AliExpress
Official Website

The Photon M3 Plus is available from $699 directly from the Anycubic site, with optional packages available that bundle Wash and Cure stations as well as resin.

4.4

Review Summary

The Anycubic Photon M3 Plus is the middle-child of the new M3 line from Anycubic, but don’t let that designation fool you into thinking it lacks distinguishing features. The M3 Plus is a large format resin 3D printer with a 6K Mono LCD that offers large parts, high resolution, and a blazing fast per-layer cure time of 1.5 seconds. In addition, the Photon M3 Plus features a unique automatic resin vat filling system, an optional camera for monitoring prints, and Wi-Fi connectivity through the newly released Anycubic Cloud ecosystem. Coming in at $699, the M3 Plus packs a lot of functionality into its ~26 lb. frame, and will no doubt be a common sight in the prosumer market.
PROS
– Innovative automatic resin vat filling system
– Laser-etched build platform
– Metal base feels robust and sturdy
– Large volume and fast build speeds

CONS
– Resin filling system may not be compatible with all resin bottles
– Anycubic cloud requires a mobile device to send prints
